49" Full HD LCD screen ,The brightness can be customized ,The brightness from 500-5000nits ,They have high quality metal frame high color saturation. original design, Stability highlight Full size design New original package display module structure and installation method thereof High flexibility, excellent heat dissipation and convenient maintenance.
Size | 49inch | |||
Panel item | RS490NET-N010 | |||
Panel type | a-Si TFT-LCD | |||
Display mode | IPS,Normally black,transmissive display | |||
Pixels | 1920*1080 | |||
brightness | 500-5000cd/m2 | |||
Constrast Ratio | 1200:1 | |||
Response Time | 6ms | |||
View angle | 89/89/89/89 (Min) | |||
View area | 1078.6*609.5mm(H*V) | |||
Dispaly area | 1076.9*607mm(H*V) | |||
Outline Size | 1106.4*641.6*47mm(H*V*D) | |||
Signal Type | LVDS | |||
Working freqyency | 60Hz | |||
Working temperature | 0- 50゚C | |||
Storage Temperature | -20 - +60゚C | |||
Display ratio | 16:9 | |||
Display color | 16.7m/1.7B | |||
Backlight Voltage | 24V | |||
Backlight Power Consumption | 220w | |||
Surface Treatment | Haze 3%,Hard coating(2H) | |||
Weight | 17.28kgs |
