Model No.: LP133WF7-SPA1
The LP133WF9-SPF2 display resolution is 1920 (RGB) × 1080 (FHD), the aspect ratio is 16:9 (width:height), and the pixels are arranged in RGB vertical stripes.
The display area size of LP133WF9-SPF2 is 293.76×165.24 (W×H) mm, the visible size is 295.76×167.54 (W×H) mm, and the appearance size is 298.76 (W)×176.24(H)×3.8(D) mm , the surface treatment is matte, Hard coating (3H).
[FHD display, high-quality image, perfect presentation of product information]
The entire FHD series of display panels are designed with a low-reflection surface to reduce the impact of ambient light sources, providing clearer images and a more comfortable viewing experience.The bright and clear display effect can attract consumers' attention. It is suitable for advertising and message transmission in retail channels, department stores, banks and public transportation facilities.
Optional size: 10.1-100 inch
Q：What are our advantages?
A：Low price high quality products, timely tracking information
Q： Can I purchase a sample for my order?
A：Yes, please feel free to contact us.
Q：Is there any other size or specification can be choose?
A：If you need different sizes or specifications, we will provide the most suitable scheme according to your requirements.
| brand | RisingStar Display (RisingStar Display) | Model name | LP133WF9-SPF2 (RisingStarD064A) |
| size | 13.3" | Screen type | a-Si TFT-LCD,Lcd Module |
| resolution | 1920(RGB)×1080 [FHD] 166PPI | Pixel configuration | RGB vertical bar |
| Display size | 293.76 × 165.24 mm (H×V) | Surface treatment | Fog surface, Hard coating (3H) |
| Visual size | 295.76 × 167.54 (H×V) mm | contrast | 1500:1 (Typ.) [transmission] |
| Brightness(cd/m²) | 400 or customized cd/m² (Typ.) | Apply to | notebook |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | Appearance of size | 298.76 × 176.24 × 3.8 mm (H×V×D) |
| Signal system | eDP (2 Lanes) , eDP1.4 , HBR1 (2.7G/lane) , termina , 30 pins | ||
| Maximum rated | Storage temperature: -20 ~ 60 °C Working temperature: 0 ~ 50 °C |
