120 Inch 5000nits Commercial Lcd Display

120 inch 5000nits Commercial Lcd Display

manufacturer BOE (BOE) model DVA10QUB-N10

Diagonal dimension 120 inch type A-Si TFT-LCD, liquid crystal glass

Resolution 3840(RGB) × 2160 UHD 40PPI Pixel arrangement RGB vertical stripe

Display area 2536.48 (horizontal) × 1470.52 (vertical) mm Appearance size 2562.48 (horizontal) × 1488.52 (vertical) mm

Open area - surface treatment Haze 1%

Display brightness 5000 cd/m ² Contrast 1200:1 (typ.)

Recommendation Perspective Full perspective response time 8 (Typ.)(G to G) ms

viewing angle 89 / 89 / 89 / 89 (typ.) (CR ≥ 10) left / right / up / down display mode Ads, black display, transmission

Substrate thickness - Color support 1.07B , 93% DCI-P3 Type of light source No backlight

weight 10.0Kgs (Typ.) Application products Digital Signage

Frame frequency 120Hz

Driver IC COF has set 24 source chips

Interface type 102 pins v-by-one 16 lane, terminal

Voltage supply 12V (Typ.)

application environment Working temperature: 0 ~ 50 ℃ ° C ; Storage temperature: - 20 ~ 60 ° C

Origin: Guangdong, China

Manufacturer: risingstarlcd
